A cornerstone of our business is the application of Passive fire protection materials. We SR Group provides supply and application of all epoxy PFP systems for different manufacturers as below:



International Paints: Chartek 7, Chartek 1709, Chartek 8, Chartek 218, Chartek 1620, Interchar 212 and Intertherm 7050.
PPG Industries: Pittchar XP.
Jotun: Jotachar JF750, Jotachar 1709 and Jotatherm TB550.
Sherwin williams: Firetex M90



For detailed project list record, kindly email us at sr@srgroup.com.sg and we will reply to you immediately.

CHARTEK 7 & 8

Chartek 7 and Chartek 8 are both high performance epoxy intumescent fire protection coating systems.The product is a high build, solvent free, two pack material providing excellent durability and combined corrosion and fire protection.Chartek 8 offers advantages in terms of lighter installed weight and mesh-free application.Both the materials are tested and certified by Lloyd's Register (LR) and Det Norske Veritas (DNV) for structural and divisional fire protection.

INTERCHAR 212

Interchar 212 is a high performance, high build, solvent free, two pack modified epoxy intumescent fireproofing coating designed to be used on steelwork requiring protection from cellulosic fires.

Independently fire tested. Recognised by FM Approvals as a Specification Tested Product in accordance with ASTM E119. Typically applied off site by specialist applicators. Interchar 212 will achieve the required fire protection thickness in only one or two coats. The product has excellent corrosion performance and mechanical properties. Interchar 212 can provide fully fire proofed steelwork without the need to topcoat. Interchar 212 is primarily a spray applied material, and performs without the requirement for any reinforcement.

INTERTHERM 7050

Intertherm 7050 is a high performance thermal insulation system based on a solvent free, 100% solids, epoxy syntactic foam.Designed to provide both thermal insulation and corrosion protection in its own right and also when used as part of the Chartek fireproofing system.Suitable for use at continuous operating temperatures from -40°C (-40°F) up to +120°C (+248°F).Application techniques include spray, trowel and moulding/casting. Intertherm 7050 is impervious to moisture and is extremely resilient to damage and chemical spills.

PITT-CHAR XP

PITT-CHAR XP offers passive fire protection solutions for the most extreme fire scenarios. The intumescent properties of PITT-CHAR XP prevent steel structures from heating up rapidly in a fire and thereby delay the loss of load bearing capacity and integrity.

In marine and industrial environments, where hydrocarbon pool and jet fires are a risk , PITT-CHAR XP buys time to enable personnel to evacuate to a safe area . The additional time provided by PITT-CHAR XP may allow the fire to be brought under control , contained and extinguished. Thereby PITT-CHAR XP works helping save lives and to protect major assets.

GALLERY

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Quisque nec erat erat. Integer blandit nulla quis fermentum hendrerit.

CHARTEK 7 & 8

Chartek 7 and Chartek 8 are both high performance epoxy intumescent fire protection coating systems.The product is a high build, solvent free, two pack material providing excellent durability and combined corrosion and fire protection.Chartek 8 offers advantages in terms of lighter installed weight and mesh-free application.Both the materials are tested and certified by Lloyd's Register (LR) and Det Norske Veritas (DNV) for structural and divisional fire protection.
